Wall Mount Fan – WMF SERIES
Large Size Wall Mount Fan
The Apogee WMF large wall-mounted fan is a space-saving high-volume ventilation solution, specially engineered for tall industrial workshops, warehouses, gymnasiums and public venues where ceiling HVLS fans cannot be installed. Different from conventional small wall fans, WMF-2000 generates huge stable airflow to circulate air over a wide radius, efficiently solving high temperature, stuffiness and poor air circulation problems.
Application Scenarios
● Factory workshops, production lines,Large warehouses & logistics storage centers
● Gymnasiums, sports halls, Exhibition halls, shopping malls and other commercial venues
● Livestock barns and greenhouses
Key Advantages
Apogee WMF-2000 large wall mount fan delivers massive airflow for factories, warehouses, gyms and commercial venues. IP65 motor, stepless speed control, wide coverage 30–35m distance.
✅ 2000mm large diameter with 6 robust blades, max airflow up to 80000 m³/min, covers 400 ㎡ area
✅ IP65 protected motor, stable operation in dusty & humid industrial environments
✅ Stepless speed regulation, wind speed adjustable from 1–8 m/s to meet diverse cooling needs
✅ Wide air throwing distance of 30–35 meters, one fan serves a large zone
✅ Heavy-duty safety mesh guard, solid wall bracket for reliable wall installation
✅ Low comprehensive power consumption (750W), energy-saving compared with multiple small fans
✅ Low noise design, running noise controlled below 62dB, comfortable for long-hour operation
Specification Table
| Item | Parameter |
|---|---|
| Model | WMF-2000 |
| Diameter | 2000 mm |
| Blades | 6 pcs |
| Voltage | 220V Single Phase |
| Max Speed | 320 rpm |
| Wind Speed | 1–8 m/s |
| Airflow | 80000 m³/min |
| Coverage Area | 400 m² |
| Rated Current | 4 A |
| Motor Power | 750 W |
| Noise | ≤62dB, Motor Noise <40db |
| Dimension | 200×200×30 cm |
| Weight | 58 kg |
| Speed Control | Stepless |
| Cover Distance | 30–35 m |
| Motor Protection | IP65 |
Notes: 220V Single phase, Motor IP65 protection，Noise < 40db
