What is the difference between industrial HVLS Fan and commercial HVLS Fan ?
The distinction between industrial-grade HVLS fans and commercial ceiling fans(home appliance)? Industrial HVLS fans lies in their design priorities, construction durability, performance, and suitability for different environments. While both move large volumes of air slowly, their engineering diverges to meet specific demands. Here’s a detailed comparison.
Key Differences Explained:
1.Environment & Durability:
Industrial: Built to withstand extreme conditions - high heat, dust, moisture, corrosive chemicals, grease, and physical impacts. They use heavy-duty materials, blades is made of aluminum alloy 6063-T6, blade hub is made of high strength steel alloy, IP65 and big torque PMSM motor, strong mounting base and 80x80 square tube as down rod.
Commercial: Designed for cleaner, climate-controlled environments like offices, stores, or restaurants. Materials are lighter (plastic, thinner gauge steel) and finishes are often more aesthetic. Durability focuses on longevity in normal indoor conditions, not extreme abuse.
2.Performance Focus:
Industrial: Prioritize high airflow volume (CFM) and often high static pressure to move air effectively despite obstructions (machinery, racks), combat heat buildup from processes, exhaust fumes, dry floors, or cool large machinery. Power and effectiveness in tough conditions are key.
Commercial: Prioritize human comfort – creating a gentle breeze for occupants. Airflow is often designed to be widespread but less forceful. Static pressure capability is lower as there are fewer obstructions to overcome. Energy efficiency for comfort cooling is a major concern.
3.Size & Airflow:
Industrial: size can be from 2.4m, 3m, 3.6m, 4.8m, 5m, 5.5m, 6.1m upto 7.3m, for example one set 7.3m HVLS industrial fan can cover 800-1500sqm big area with only 1kw/hour, the air volume can reach 14989m³/min.
Commercial: the size are mostly 1.5m, 2m, 2.4m upto 3m. the air volume is only 1/10 of HVLS ceiling fan, always installed the height below 5m.
4.Controls & Features:
Industrial: Controls are often basic (on/off, speed) with knob. Focus is on reliability and function. While Apogee designed control panel is touch screen which is durable and customized, visible speed.
Commercial: Often feature-rich: remote controls, multiple speed settings, timers, oscillation, thermostats, and increasingly, smart home integration (WiFi, apps).
5.Cost:
Industrial: Higher initial cost due to heavy-duty materials, powerful motors, and robust construction. Justified by longevity and performance in harsh settings.
Commercial: Generally lower initial cost, focusing on value and features for comfort. Durability expectations are lower.
In Summary:
*Choose an Industrial Fan if you need maximum durability, high airflow/pressure, and reliability in a tough environment (factory, workshop, barn, dusty warehouse) it can be used in big and high space. Even though the cost is little higher, if consider it’s value, long lifetime 15years, green energy saving only 1kw/hour, it is a very effective and economic product.
Under the industrial design structure, we bring out Commercial HVLS Fans, it cover 2m. 2.4m, 3m, 3.6m, 4.2m, 4.8m. which is commercial design with quiet, durable material, and long lifetime 15years.
*Choose a Commercial Fan if you need air circulation at home or small space, low height, commercial fan is optional. quiet, and aesthetically pleasing comfort cooling for people in typical indoor spaces (office, store, restaurant, home).
Assess your environment, primary need (combat heat/dust vs. human comfort), and durability requirements to pick the right type.
If you have HVLS Fans inquiry, please contact us through WhatsApp: +86 15895422983.
